Get Ready with Below Points
- Ensure that your laptop‘s USB-C port supports the?Power Delivery. DP Alt Mode and Data Transfer?to access the full feature of this USB-C hub.
- Not all laptop’s USB-C port support video output.?Only USB-C port that support the DP protocol can support external displays. the DP1.4 protocol support resolution up to 4K120Hz.
- If you don’t have enough knowledge about it.?be free to reach our support team?by providing your laptop‘s brand and model so that we could help you out.
?
Up to 120HZ High Refresh Rate
The Maximum display output resolution up to 4K@120Hz with HDMI 1 while single display. also backwards with 4K@60Hz / 2K@120Hz / 1080P@60Hz
?
NOTE with 120HZ Output:
- The USB-C port of laptop must?support the DP1.4 protocol.
- External Monitor?must support 120HZ or Higher Refresh Rate.
- Only HDMI 1 of dock output up to 4K@120Hz. HDMI 2 display up to 4K@30Hz.
?
Other NOTES:
- When more external devices are connected through this hub. it is recommended to connect with power supply through the USB-C PD port.
- For MacBook users. settings are required to use LAN ethernet port. Go to: System Preferences ?C Network. click on + icon and selecting usb 10 / 100 / 1000 LAN to create an application
- If the HDMI isn‘t stable when extending on monitor. ensure to firmly plug the HDMI cable and assure that the hub is powered through the USB-C port
- This USB-C hub docking station much be directly plug to the USB-C port of your laptop. It may not work if plugged to a convert or other port adapters.
- Some users’ laptop upgrade from Windows 10 to Windows 11. which cause the USB-C interface of laptop cannot recognize the usb c hub. Please upgrade the USB-C interface driver of laptop
- Some laptop interface have an over-discharge protection protocol. Please keep the PD adapter connected with docking station while using for a long time.
?
MAC User Must Pay Attention.
Due to the limitation of Mac system. 2 external monitors will display the same content(such as A+B+B). 3 different screens can not be achieved.
USB-C Fast Power Delivery
The PD charging port supports delivering power to your devices quickly. You can use this docking station to power your laptop with the original power supply.
?
Expansion for USB devices
2*USB 3.0 Ports with 5Gbps transfer speed and 1*USB 2.0 Port with 480Mbps transfer speed. also allows you to connect keyboard or mouse without any lag.
?
USB C SD Card Reader
The SD/TF Card reader can read at the same time. immediately transfer pictures to your phone. tablet or laptop everywhere.(Speed up to 104 MB/s)
Gigabit Network Port
Get a stable high-speed network connection on the USB-C device. Supports max 1000Mbps ethernet. backwards compatible with 100Mbps/10Mbps RJ45 LAN.
?
Unique Indicator Light
The baseus uniquely designed indicator shines icy blue light. can visually display the working status of the USB C hub but not disturbing you at night.
?
Design Awards We’ve Earned
Baseus originates from our core value Based on User. With more than a decade of focus on consumer electronics. innovation and creativity led us to where we are right now with numerous patents. international design awards. and a vast variety of product.
?
Compatible Device’s Models
?
|
For Apple: |
|
MacBook/ MacBook Pro(2021/2020/2019/2018); Macbook Air 2018-2020. Mac mini 2018-2020. iPad Pro/Air 2018/2020. iPad mini 6 |
|
For Dell: |
|
Dell XPS 9380/ XPS 13 9365/ XPS 15 2018/ XPS 13 9300; Dell Latitude 5290 2 in 1/5285/5480/5490/5580/7280/Dell Latitude E7370/E7470/E7480/E7490/ laptop/Dell Latitude 13 7000/E7370L/New XPS 15 i7 |
|
For Lenovo: |
|
Lenovo Yoga 720-13IKB/ Yoga 730/ Yoga 900-13ISK/ Yoga 910/ Yoga 920/ Yoga 930/ Yoga 940-14IIL; 3rd generation Thinkpad Yoga; Yoga15 Thinkpad Ultrabook Pro; Thinkpad E590/ Thinkpad P72/ Thinkpad T470/ Thinkpad X1 Carbon (2019 model); Lenovo C930/ T480s/ X390/ 81N8 |
|
For Surface: |
|
Microsoft Surface Book 2/ Surface Laptop 3; Surface Pro 7/Surface Pro 8/Surface Go |
|
For Samsung: |
|
Samsung Galaxy S10+/S10/S9+ /S9 /S8+ /S8 Plus; Note 10/9/8; Galaxy Book Flex Alpha 2-in-1 13.3 QLED Touch-Screen Laptop; Galaxy Tab S5e/ Galaxy Tab S4; Galaxy S20 Ultra |
|
For HP: |
|
HP Spectre Laptop 13-af001TU/ Spectre x360 13t/ Spectre folio (13t-ak000cto)/ Spectre 360 laptop/ Specter x369; Elitebook 840 G5 series/ Elitebook X2/ Elitebook x360 1030 G3/ Elitebook 745 G6/ Elitebook 830 G6/ 2018 HP Elite 800 G4; Envy Geforce mx250/ Envy x360 Laptop (15z-ds100); Z book 15u G3/ Zbook 17 G4 |
|
For ASUS: |
|
13” ASUS Zenbook UX330UA/ Zenbook Flip ux370u; ASUS TUF Gaming A15 Gaming Laptop |
|
For Acer: |
|
Acer Aspire 5 2019; D17w3 Aspire c24-865 |
|
For Games: |
|
Steam Deck |
|
Other Laptops: |
|
Google Slate (2019); SanDisk Cruise Glide; Razer Blade 2017 (gtx 1060); Pixel book go 2019/2020. Google Chromebook Pixel Book; 13” ASUS Zenbook UX330UA; LG G5. LG gram 14Z990-V.AA52C |
1 x USB-A 2.0
1 x USB-A 2.0
1 x USB-C 3.0
2 x USB-C 2.0
